| NO。OF Phases/絲桿電機相數 | 2P | Step length/整步步長 |
|
| Step angle/絲桿電機步距角 | 1.8o ±5% | Insulation Class/絕緣等級 | B |
| Rated voltage/額定相電壓 |
2.6V |
Working Temperature/工作溫度 | -20OC~~+50OC |
| Rated current/額定相電流 | 1.5A |
Inertia/轉子慣量 |
35g.C㎡ |
| Resistance/相電阻 | 1.8Ω | Temperature Rise/溫升 | 80KMAX。 |
| Wire rod diameter/絲桿直徑 | 8.0MM | Weight/電機重量 |
|
| Screw thread lead/絲桿螺紋導程 | 2MM | Accuracy grade/精度等級 | C7 |
| Number of threads/螺紋頭數 |
3 |
insulation resistance/絕緣電阻 | 100MΩmin500VDC |
| Type of wire rod/絲桿種類 | 滾珠絲桿 | Encoder specifications/編碼器規格 |
4000ppr（1000線） |
