| NO。OF Phases/絲桿電機相數(shù) | 2P | Step length/整步步長 | 0.015MM/步 |
| Step angle/絲桿電機步距角 | 1.8o ±5% | Insulation Class/絕緣等級 | B |
| Rated voltage/額定相電壓 |
3.0V |
Working Temperature/工作溫度 | -20OC~~+50OC |
| Rated current/額定相電流 | 1.5A |
Inertia/轉子慣量 |
110g.C㎡ |
| Resistance/相電阻 | 2.7Ω | Temperature Rise/溫升 | 80KMAX。 |
| Wire rod diameter/絲桿直徑 | 6.35MM | Weight/電機重量 | 230g |
| Screw thread lead/絲桿螺紋導程 | 3.175MM | Holding torque/標準推力 | 60-70N |
| Number of threads/螺紋頭數(shù) |
1 |
Minimum thrust/最小推力 | 60N/10-24MM/S |
| Type of wire rod/絲桿種類 | 梯形絲桿 | Wire rod material/絲桿材質 |
不銹鋼ACME |
