| NO。OF Phases/絲桿電機相數 | 2P | Step length/整步步長 | 0.025MM/步 |
| Step angle/絲桿電機步距角 | 1.8o ±5% | Insulation Class/絕緣等級 | B |
| Rated voltage/額定相電壓 |
4.0V |
Working Temperature/工作溫度 | -20OC~~+50OC |
| Rated current/額定相電流 | 5.0A |
Inertia/轉子慣量 |
690g.C㎡ |
| Resistance/相電阻 | 0.46Ω | Temperature Rise/溫升 | 80KMAX。 |
|
Type of wire rod/絲桿種類 |
滾珠絲桿 |
Weight/電機重量 | 920g |
|
Wire rod material/絲桿材質 |
高碳鉻軸承鋼 |
Holding torque/標準推力 | 550-450N |
| Number of threads/螺紋頭數 |
2 |
Minimum thrust/最小推力 | 450N/5-50MM/S |
